2.4GHz Wireless Video Transmitter Set, Alarm, Audio

$345.00
In stock
Only 3 left
SKU
TV2400
  • 2.4GHz Wireless Video Transmitter
  • Up to 250ft
  • Signal can be amplified up to 1500ft
  • Line of Sight Transmission
  • Transmits Audio, Video, Alarm Inputs
  • 12V DC

2.4GHz Wireless Video Transmitter Kit come with a 2.4GHz Wireless Video Receiver for wireless transmission up to 250ft away with clear unobstructed line of sight. This wireless video transmitter kit comes with a RF transmitter with de-scrambling technology to work with the receiver. In addition to transmitting video signals, it can also transmit audio and alarm inputs.

This 2.4GHz wireless video transmitter set is great for converting a wired analog security camera in to wireless because it transmits a Real Time video signal without any lag. Note that only the following signal types are supported by this video transmitter kit:

  • 480P or D1 Analog resolution video (CVBS)
  • 960H Analog resolution video (CVBS 960H)
  • 720P AHD

Other types of security cameras like HDCVI or HDTVI are incompatible. Resolutions above 720P are incompatible.

Video transmission quality is almost as good as wired cameras, as long as there is unobstructed line of sight in the signal path and proper types of antennas are used to maintain good signal strength.

You can also amplify the transmission strength by adding a 2.4GHz high gain antenna. If you're looking to transmit farther than 250ft, use of compatible antennas such as the 16dbi 2.4GHz panel antenna or the 9dbi 2.4GHz high gain directional panel antenna is required. Third-party antennas will not work and lead to signal loss. With a 16dbi antenna on both sides you can expect up to 2000ft of wireless transmission, and with a 9dbi antenna on both sides you can expect up to 700ft transmission distance. Even with high gain antennas for optimal performance unobstructed line of sight is required between the antennas.

Wondering how good this wireless video transmitter is? then watch the wireless transmitter strength video below. We place a box filled with power supplies in between the transmitter and receiver and show the signal transmission to be flawless.

Features

  • 2.4GHz Wireless Signal to prevent interference from 2.4GHz wireless WiFi networks and radios
  • Up to 250ft transmission distance in an unobstructed clear line of sight with the included 3dBi Omni Antenna
  • Up to 2000ft wireless video transmission range with the 2.4GHz high gain directional antenna 16dBi placed at both transmitter and receiver
  • 4 Selectable 2.4GHz Channels
  • 4 Sets of transmitter and receiver can be used in one location without cross interference
  • Multiple wireless receivers can be used to receive one wireless signal, so the same camera can be watched in multiple locations
  • More transmitter/receiver pairs can be used in one location with the use of directional antennas to limit cross interference
  • RCA Audio and BNC Video Inputs
  • Built-in video scrambling and ID addressing for secure video transmission
  • Must be enclosed in outdoor NEMA enclosure

What's included?

  • (1) 2.4GHz Wireless Video Transmitter
  • (1) 2.4GHz Wireless Video Receiver
  • (2) 2.4GHz Omni directional antenna 3dBi
  • (1) 12V DC 1.5A Power Adapter for Transmitter
  • (1) 12V DC 1A Power Adapter for Receiver

Specifications

Frequency Channels 2414 - 2468 MHz, 4 CH
RF TX/RX Power 10mW
RF Impedance 50 Ω
BNC Video Input/Output 1.0 Vp-p Composite @ 75Ω
RCA Audio Input/Output 3.0 Vp-p Max. (600Ω)
Alarm Level Detection (5V TTL)
Power Consumption DC 12V/250mA (Start-up Current: DC 12V/500mA)
Weather Proof No
Operation Temperature 14° - 120°F
Dimensions 11 x 8.8 x 3cm (without Antenna)

More Information
Return Policy30 Days Return Policy
Warranty1 Year
