| Camera |
| Image Sensor |
1/3" 4MP CMOS |
| Effective Pixels |
2592 (H) x 1520 (V) |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
1/1 – 1/30,000s |
| Min. Illumination |
Color: 0.05Lux at F1.6, B&W: 0.005Lux at F1.6 |
| S/N Ratio |
More than 50dB |
| IR Distance |
None |
| IR On/Off Control |
No |
| IR LEDs |
None |
| Lens |
| Focal Length |
2.7–11mm, (4X Optical Zoom) |
| Max Aperture |
F1.6 – F2.8 |
| Angle of View |
H: 112.5°–30° |
| Focus Control |
Auto / Manual |
| Close Focus Distance |
3.94" - 39.4" |
| Digital Zoom |
16X |
| Max Distances* at 4X Zoom |
| Detect |
Observe |
Recognize |
Identify |
| 591ft |
236ft |
118ft |
59ft |
|
| Video |
| Video Interface |
IP (Network Based Camera) |
| Compression |
H.265, H.264 |
| Streams |
Main Stream, Sub Stream 1, Sub Stream 2 |
| Resolution |
4MP (2592x1520), 3MP (2304x1296), 1080p (1920x1080) / 720P (1280×720) / D1 (704×480) |
| Frame Rate |
Main Stream: 4MP, 3MP, 1080P, 1.3MP, 720P (1-30fps)
Sub Stream 1: D1, CIF (1 – 30fps)
Sub Stream 2: 720P, D1, CIF (1-30fps) |
| Bit Rate |
H.265/H.264: 448K – 8192Kbps |
| Day/Night |
Auto(ICR), Color, B/W |
| Backlight Compensation |
BLC, HLC, WDR 120db |
| White Balance |
Auto, ATW, Indoor, Outdoor, Manual |
| Gain Control |
Auto, Manual |
| Noise Reduction |
Ultra DNR (2D/3D) |
| Motion Detection |
Yes, stream compatible w/ specific NVR or Software |
| Region of Interest |
Yes |
| Electronic Image Stabilization |
No |
| Defog |
Yes |
| Image Flip |
180° |
| Privacy Masking |
Up to 24 areas |
| Video Analytics |
| Auto Tracking |
No |
| Video Analytics |
Tripwire, Intrusion, Abandoned/Missing Object Detection |
| Audio |
| Compression |
None |
| Audio Interface |
None |
| PTZ |
| Pan/Tilt Range |
Pan: 0° – 355°; Tilt: 0° – 90° |
| Manual Control Speed |
Pan: 0.1° – 100° /s; Tilt: 0.1° – 60° /s |
| Preset Speed |
Pan: 100° /s; Tilt: 60° /s |
| Preset |
300 |
| PTZ Mode |
5 Patterns, 8 Tour, Auto Pan, Auto Scan |
| Speed Setup |
Human-oriented focal length/ speed adaptation |
| Power up Action |
Auto restore to previous PTZ and lens status after power failure |
| Idle Motion |
Activate Preset/ Scan/ Tour/ Pattern if there is no command in the specified period |
| Protocol |
PelcoD, DH-SD, ONVIF |
| Network |
| Ethernet |
RJ-45 (100Mbps) |
| Protocol |
IPv4/ IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1X |
| Compatibility |
ONVIF Profile S & G |
| Max. User Access |
20 users |
| Recording Methods |
NAS, Local PC, MicroSD, NVR, FTP |
| Smart Phone |
iOS, Android |
| Web Viewing |
Chrome, Firefox, Safari, IE** (learn more) |
| Other Connections |
| Memory Slot |
microSD, Max 256GB (not included) |
| BNC |
No |
| RS485 |
No |
| Power |
12V DC |
| WiFi |
2.4GHz 802.11 a/b/g/n (no mesh) |
| Alarm |
No |
| General |
| Power |
DC12V 1.5A |
| Power Consumption |
10W |
| Operating Temperature |
-22°F to +140°F, Less than 95% Relative Humidity |
| Weather Proof |
Yes IP66 |
| Vandal Resistance |
IK10 Impact and Vandal Resistant |
| Dimensions |
4.8" (diameter) x 3.5" (height) |
| Construction |
Metal |
| Weight |
1.6 lbs |
