| Image Sensor |
1/2.8" 2MP Sony Starvis CMOS |
| Effective Pixels |
1920 (H) x 1080 (V) |
| Electronic Shutter Speed |
Auto/Manual, 1/1- 1/30000s |
| Minimum Illumination |
0.005 Lux F1.6 (Color), 0.0005 Lux F1.8(B/W), 0 Lux IR On |
| S/N Ratio |
More than 50dB |
| IR Distance |
Up to 50ft |
| IR On/Off Control |
Auto, Manual |
| IR LEDs |
3 IR LED |
| Lens Type |
Motorized Zoom |
| Focal Length |
2.7mm - 8.1mm |
| Max Aperture |
F1.8 |
| Angle of View |
Horizontal: 105.6° – 35.2° |
| Close Focus Distance |
4 inches at Wide View, 39.5 inches at Tele View |
| Focus Control |
Auto, Manual |
| Close Focus Distance |
4" (wide), 40" (tele) |
| Max Distances* at 3X Zoom |
| Detect |
Recognize |
Identify |
| 160ft |
100ft |
60ft |
|
| Compression |
H.265+, H.265, H.264+, H.264 |
| Pan Tilt Range |
Pan: 0° - 355°, Tilt: 5° - 90° |
| Manual Control Speed |
Pan: 0.1° - 70° /s; Tilt: 0.1° - 30° /s |
| Preset Speed |
Pan: 80° /s; Tilt: 40° /s |
| Presets |
300, 8 Tours |
| Power Up State |
Auto restore to previous PTZ and lens status after power failure |
| Idle State |
Continue Preset/Tour if there is no command in the specified period |
| Auto Tracking |
No |
| Video Analytics |
Tripwire, Intrusion, Abandoned and Missing Object Detection |
| Streaming Capability |
3 Streams (Main Stream, Sub Stream 1, Sub Stream 2) |
| Resolution |
1080P (1920x1080), 720P (1280x720), D1 (704x480), VGA (640x480), CIF (342x240) |
| Frame Rate |
Main Stream: 1080P / 720P (1-30fps), Sub Stream 1: D1 / CIF (1-30fps), Sub Stream 2: 720P / D1 / CIF (1-30fps) |
| Bit Rate Control |
CBR, VBR |
| Bit Rate |
H.265 or H264: 448K - 8192Kbps |
| Day/Night |
Auto (ICR), Color, B/W |
| BLC Mode |
BLC, HLC, WDR 120db |
| White Balance |
Auto, ATW, Indoor, Outdoor, Manual |
| Gain Control |
Auto, Manual |
| Noise Reduction |
Ultra DNR (2D/3D) |
| Motion Detection |
Off / On (4 Zone, Rectangle) |
| Region of Interest |
Off / On (4 Zone) |
| Smart IR |
Yes |
| Digital Zoom |
16X |
| Defog |
N/A |
| Flip |
180° |
| Mirror |
Off / On |
| Privacy Masking |
Off / On (24 Area, Rectangle) |
| Audio Input |
Built-in Mic, Audio Line-In and Out |
| Audio Compression |
G.711a/G.711mu/G.726/AAC |
| Alarm |
None
|
| Ethernet |
RJ-45 100Mbps |
| Protocols |
HTTP, HTTPs, TCP, RTSP, RTMP, RTP, UDP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, IPv4/v6, QoS, UPnP, NTP, Bonjour, 802.1x, Multicast, ICMP, IGMP, SNMP |
| Interoperability |
ONVIF Profile S & G |
| Streaming Method |
Unicast / Multicast |
| Max. User Access |
20 Users |
| Recording Method |
NVR, NAS, Local PC, Optional MicroSD card 256GB |
| Web Viewer |
Chrome, IE** |
| Smart Phone |
iOS or Android |
| Power Supply |
12V 2A DC or PoE (802.3af) |
| Power Consumption |
7.8W (IR off), 10.5W (IR on) |
| Operating Conditions |
-22°F – +140°F, Less than 95% RH |
| Weather Protection |
IP66 |
| Vandal Resistance |
IK08 |
| Casing |
Metal |
| Dimensions |
5.1" x 2.5"(diameter x height) |
| Net Weight |
1.1 lbs |
| Certifications |
CE, UL, FCC Part 15 Subpart B |
