Mount Adapter for Mini PTZ Cameras
- Metal Mounting Plate
- For connecting select mini PTZ cameras
- Connect to wall mount JB305W
- Connect to ceiling mount JB220
Metal construction mounting plate for use with select model mini PTZ cameras that we carry. It is for use in professional installations where you would like to suspend one of our compatible mini PTZ cameras from the wall using the JB305W arm mount or the ceiling using our JB220 ceiling mount. The camera locks in to this mounting plate using a mechanism similar to a smoke detector. The metal plate mounting plate that comes with the cameras for ceiling installation is required. The camera's pigtail would thread through this mounting plate and through the arm or ceiling mount to conceal the cables from would-be vandals. This item is available in white only.
This item will work with the following model cameras only:
- WiFi Mini PTZ with Night Vision, 2K, Built-in Microphone, 4X Zoom, sku IPD3X4MWIFI
- 2K Mini PTZ PoE, Night Vision, Audio, Outdoor, sku IPSDIR3X4M
- Outdoor PTZ Camera with Microphone and Night Vision, sku IPSDIR3X
If you would like to use a camera you did not purchase from us, it would be at your own risk.
What's included?
- (1) Wall mount adapter
Material | Aluminum |
Dimensions | 13.41cm diamter x 8.35cm height |
Pipe Thread | 4.68cm diameter |
Operating Temperature | -40°F - +140°F |
Humidity | 0-90% RH |
Load Bearing | 1Kg |
Weight | 0.29Kg |
Brand | CCTV Camera World |
---|---|
Return Policy | Accessories are non-returnable, non-refundable. |
Warranty | None for accessories |
