| Camera |
| Image Sensor |
1/1.8" Sony Starvis CMOS |
| Effective Pixels |
3840 (H) x 2160 (V) |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
1/1 – 1/30,000s |
| Min. Illumination |
Color: 0.005 Lux @ F1.4; 0 Lux IR on |
| S/N Ratio |
More than 56dB |
| IR Distance |
500 ft |
| IR On/Off Control |
Auto, Manual |
| Lens |
| Focal Length |
5.4mm – 135mm, (25X Optical Zoom) |
| Max Aperture |
F1.6 – F4.0 |
| Angle of View |
H: 61.6°–3.6°; V: 35.7°–2° |
| Focus Control |
Auto / Manual |
| Close Focus Distance |
1.64ft - 22.97ft |
| Digital Zoom |
16X |
| Max Distances* at 25X Zoom |
| Detect | Observe | Recognize | Identify | | 8858ft | 3498ft |
1772ft |
886ft |
|
| Video |
| Video Interface |
IP (Network Based Camera) |
| Compression |
H.265+, H.265, H.264+, H.264 |
| Streams |
Main Stream, Sub Stream 1, Sub Stream 2 |
| Resolution |
Main stream: 4K, 1080P, 1.3MP, 720P
Sub Stream 1: D1, CIF
Sub Stream 2: 1080P, 720P, D1 |
| Frame Rate |
8MP / 1080P / 720P / D1 / CIF (1-30fps) |
| Bit Rate |
H.265/H.264: 256 – 8192Kbps |
| Day/Night |
Auto(ICR), Color, B/W |
| Backlight Compensation |
BLC, HLC, WDR |
| White Balance |
Auto, ATW, Indoor, Outdoor, Manual |
| Gain Control |
Auto, Manual |
| Noise Reduction |
Ultra DNR (2D/3D) |
| Motion Detection |
Yes, stream compatible w/ specific NVR or Software |
| Region of Interest |
Yes |
| Electronic Image Stabilization |
Yes |
| Defog |
Yes |
| Image Flip |
180° |
| Privacy Masking |
Up to 24 areas |
| Video Analytics |
| Auto Tracking |
Yes |
| Video Analytics |
Tripwire, Intrusion, Abandoned/Missing Object Detection |
| Audio |
| Compression |
G.711a, G.711Mu, AAC, PCM, G.726, G722.1, G.729 |
| Audio Interface |
1 Channel In/Out via 2 lead wire (read more) |
| PTZ |
| Pan/Tilt Range |
Pan: 0° – 360° endless; Tilt: -15° – 90°, auto flip 180° |
| Manual Control Speed |
Pan: 0.1° – 300° /s; Tilt: 0.1° –200° /s |
| Preset Speed |
Pan: 400° /s; Tilt: 300° /s |
| Preset |
300 |
| PTZ Mode |
5 Pattern, 8 Tour, Auto Pan, Auto Scan |
| Speed Setup |
Human-oriented focal length / speed adaptation |
| Power up Action |
Auto restore to previous PTZ and lens status after power failure |
| Idle Motion |
Activate Preset/ Pan/ Scan/ Tour/ Pattern if there is no command in the specified period |
| Protocol |
Pelco D, Pelco P, or ONVIF |
| Network |
| Ethernet |
RJ-45 (Up to 1000Mbps) |
| Protocol |
IPv4/ IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS |
| Compatibility |
ONVIF, PSIA, CGI |
| Max. User Access |
20 users |
| Recording Methods |
MicroSD, NVR, NAS, Local PC, FTP |
| Smart Phone |
iOS, Android |
| Web Viewing |
IE**, Chrome, Edge |
| Other Connections |
| Memory Slot |
MicroSD Max 256GB (not included, factory installed option) |
| BNC |
Yes |
| RS485 |
Yes |
| Power |
2 Lead wire |
| Alarm |
2/1 channel In/Out |
| General |
| Power |
PoE+ 802.3at compliant or 24V AC 2.5A |
| Power Consumption |
11W, 20W (IR On) |
| Operating Temperature |
-40°F to +140°F, Less than 95% Relative Humidity |
| Weather Proof |
Yes IP67 |
| Wiper |
No |
| Vandal Resistance |
No |
| Dimensions |
7.5" × 13.1" (Diameter x Height) |
| Construction |
Metal |
| Weight |
11 lbs |
