32 Channel 2K DVR

100% of 100
Special Price $599.99 Regular Price $799.99
Out of stock
Special Order, 8-10 week delivery time estimated
  • 32 Camera 2K DVR
  • Records Total of 32 Channels
  • Records up to 5MP IP Cameras
  • Records up to 4MP HD over Coax
  • Records Analog, HDCVI, TVI, AHD Cameras
  • 1 Audio Input
  • Up to 20TB, 2HDD Capacity
  • HDMI/VGA/BNC Video Out

This 32 Camera DVR accepts five different types of videos signals. If you're looking to build a new security camera system or upgrade your existing DVR, this unit is perfect for either. You can use older analog CCTV cameras, newer HD security cameras over coax up to 2K resolution, and IP cameras up to 5MP. It is an affordable yet powerful 32 channel security DVR with a plethora of features. If you need more than 20TB of storage space, then you may want to consider its larger sibling the 32 Channel Enterprise DVR that can hold up to 8 hard drives.

This 32 Channel Digital Video Recorder is our newest generation of security camera recorders classified as XVRs, which means it can record up to five different types of video signals. You can record the following signal types with this XVR:

  • HDCVI - you can choose from our selection of HDCVI cameras here up to 4MP in resolution. HDCVI signals allow for audio and PTZ controls to be sent over coax wire.
  • AHD - our 4 in 1 cameras allow output of this signal type, however AHD is not very popular in the USA.
  • TVI - our 4 in1 cameras allow output of TVI signals.
  • IP Cameras - you can select from any of our IP cameras up to 5MP resolution that have guaranteed compatibility with our recorders. This DVR supports up to 128Mbps of IP camera encoding bandwidth.
  • Analog Cameras - these are standard definition security cameras that you probably already have if you have an existing camera system.

This 32 Camera XVR supports any combination of the above five camera signals up to 32 channels. It allows channel type to be changed for each channel so you can have a heterogeneous mix of cameras, see here how it is done. You can switch channels between coax and IP input type. For IP cameras you will need a PoE switch to power and send data/video to establish a network between the cameras and the DVR.

Most importantly, this 32 camera DVR supports IP cameras on each channel. Don't be fooled by competitor Tribrid or Hybrid DVRs that support only up to 2 or 8 IP cameras on their DVR. We can only support IP cameras purchased from CCTV Camera World.

The 32 Channel XVR also allows you to select the resolution you would like to record for each camera independently, and set motion recording and video motion detection areas. You can also set highly customized recording schedules for each channel based on your own preferences. You can take advantage of intelligent Smart Detection video analytics such as tripwire to fine tune event detection.

To conserve hard drive recording time this DVR has the latest H.264+ video compression technology that records great quality video while saving up to 50% storage space compared to conventional H.264 encoding.

This security DVR recorder controls compatible HDCVI PTZ cameras over the same coax wire, eliminating the need to run an extra 2-lead wire for RS485. However, if you have older analog PTZs with RS485, it can control them as well.

Adding a security camera with microphone is easy. This recorder support audio over the HDCVI signal, meaning you can use a HDCVI camera with built-in microphone to capture video + audio over the coax wire. There is one RCA audio input that allow you to tie in a security camera microphone. It has two-way audio talk functionality where you can connect a microphone and speaker to hear from and talk back to one location.

Backing up video is also very easy. You can backup to a USB drive or over the network to a computer. Remote viewing your security cameras is easy with our Free Apps for iOS, Android, Windows and Mac.

If you need help, you get free tech support with your purchase from CCTV Camera World.


  • 32 Channel 2K DVR
  • Pentabrid DVR technology supports:
  • Captures HD video over coaxial cable or over IP network
  • View and record up to 4MP HD security cameras over coax
  • H.264+, H.264 Video Encoding
  • Selectable recording resolutions and frame rates per camera
  • Selectable HD Over Coax recording resolutions: 4M-N, 1080P, 1080N, 720P, 960H, D1, 2CIF, CIF
  • Selectable IP Camera recording resolutions: 5MP, 4MP, 3MP, 1080P, 720P, CIF
  • Several Recording Modes:
    • Continuous 24/7 Recording
    • Schedule recording - record only at certain times and days
    • Motion detection - record only when the motion is detected in the video analyzed by the DVR
    • Video Analytics - use tripwire, abandoned/missing object detection, or face detection to event detection
  • Full set of controls (all free of charge) when remotely viewing using a computer:
    • View Live Video from all 32 Cameras in a grid or each camera individually
    • Playback recorded video from cameras in a grid up to 16 cameras or each camera individually
    • Backup video segments over internet on to your computer
    • Bandwidth Management for slow internet connections so smaller images are displayed faster
    • Supports up to 20 remote viewers simultaneously
    • Motion activated Email alerts or push notifications to mobile devices without monthly charges
  • Support up to 2 hard drives for a total 20TB storage capacity
  • Automatic hard drive overwrite to recycle over the oldest recorded video first
  • FREE CMS Software for viewing multiple systems over internet using Windows PC or MAC Computer
  • FREE Phone Apps for viewing on iPhone, iPad, Android devices
  • Easy to connect to phone using port forwarding or QR code connection
  • Automated push alerts to your mobile phone when motion occurs
  • Advanced User Rights Management: Supports multiple user accounts with selectable authorization levels
  • Multiple Video Outputs
    • (1) 1080P High Definition HDMI - Main Out
    • (1) VGA 1080P connection - Main Out
    • (1) BNC - Spot Out
  • Compatible with Network PTZ Controller to control RS485 and Network PTZ Cameras
  • ONVIF 2.42 Compliant

Connectors on this DVR include

  • (32) BNC video inputs
  • (1) RCA audio input
  • (1) RCA audio output
  • (1) VGA video output
  • (1) HDMI video/audio output
  • (1) BNC video output
  • (2) USB ports
  • (1) RS485 Port
  • (1) RJ45 Ethernet

What's Included?

  • (1) 32 Channel Mini Security DVR
  • (1) Power Cord
  • (2) SATA Cables
  • (1) USB mouse


Main ProcessorEmbedded Processor
Operating SystemEmbedded Linux
Video Outputs1 HDMI (Main), 1 VGA, 1 BNC
Output Resolution1920x1080, 1280x1024, 1280x720, 1024x768
Grid Displays1, 4, 8, 9, 16, 25, 36 Channels
On Screen DisplayCamera Title, Time & Date Stamp, Video Loss Alert, Motion Event, Recording
Video DetectionMotion Detection, Motion Zones: 396 (22 x 18), Video Loss, Tampering and Diagnosis, Smart Detection
Trigger EventsRecording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Alarm inputsNone
Alarm Relay OutputsNone
Video Playback1, 4, 9, 16 up to 4M-N
Search ModeTime /Date, Motion Detection, Smart Detection, and Exact Search (accurate to second)
Playback FunctionPlay, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
Backup ModeUSB Flash Drive, External USB Burner, Network
Internal HDD2 SATA Ports, 10TB ea. Total 20TB
USB(1) USB 2.0, (1) USB 3.0
RS4851 Port for 3rd Party PTZ Control
3rd Party IP Camera SupportAvalonix, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more
BNC Input32 Channels
IP Camera Input32 Channels up to 5MP (shared with BNC channels)
Audio In/Out1 in, 1 out BNC
Two-way TalkReuse audio in/out BNC

BNC: 4M-N, 1080P, 1080N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF

IP: 5MP, 4MP, 3MP, 1080P, 720P, D1, CIF

BNC Record RateMain stream: 4M-N/1080P (1-15fps), 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF (1-30fps)
Sub stream: D1/CIF/QCIF(1-15fps)
BNC Bit Rate1Kbps - 6144Kbps Per Channel
IP Record RateDependent on camera up to 5MP
IP Record Bandwidth128 Mbps
Record ModeManual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop, Smart Detection
Record IntervalPre-record: 1-30 sec, Post-record: 10- 300 sec
Record File Lengths1-60 min (default: 60 min)
Smart DetectionTripwire, Abandoned/Missing Object Detection, Face Detection on BNC inputs
Network Ports 1 RJ-45 Ports (1000Mbps)
Network FunctionHTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Supports Avalonix IP camera, DVR)
Max User Accounts64 users
Smart PhoneiPhone, iPad, Android
OnvifONVIF 2.42, CGI Conformant
Power Supply12V DC 5A
Power Consumption20W (Without HDD)
Operating Conditions+14°F - +131°F, 0-90% RH
Dimensions14.8" x 11.3" x 2.1"
Net Weight7.2 lbs (without HDD)
InstallationFlat table top / shelf
CertificationsCE, UL, FCC Part 15 Subpart B
More Information
Recording Resolutions5MP, 4MP, 4M-N, 3MP, 1080P, 1080N, 1.3MP, 720P, D1
Total Incoming IP Bandwidth128 Mbps
Total IP Recording Bandwidth128 Mbps
eSATA PortNone
USB Ports(1) USB 2.0, (1) USB 3.0
Video Outputs(1) HDMI, (1) VGA, (1) BNC
Power Input12V DC
BNC Recording Frame Rate4M-N/1080P (1-15fps), 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF (1-30fps)
Number of Audio Inputs1 RCA
Encoding SupportedH.264/H.264+
Number of PoE InputsNone, uses network for connection
Max Hard Drive Capacity2HDD, 16TB
Hot Swap HDDNo
RAID RedundancyNo
Warranty1 Year
Recorder TypeDVR Pentabrid Type XVR
CPUEmbedded Dual Core
Total Cameras Supported32
Supported Camera SignalsAnalog, HDCVI, TVI, AHD, IP
Number of BNC Inputs32
Number of IP Cameras Supported32
Total PoE PowerNo Built-in PoE Ports
Return Policy30 Days Return Policy
